Description
Door Station/System Parameters
- Processor: High-Performance Embedded SOC Processor
- Operation System: Embedded Linux Operation System
Door Station/Video Parameters
- Camera: CMOS Low Illumination 2 MP HD Colorful 155° Fisheye Camera
- Resolution: 1920 × 1080
- Video Frame Rate
- NTST: 30 fps
- PAL: 25 fps
- Video Compression Standard: H.264
Door Station/Audio Parameters
- Audio Input: Built-in Omnidirectional Microphone
- Audio Output: Built-in Loudspeaker
- Quality: Noise Suppression and Echo Cancellation
- Audio Compression Standard: G.711 U
- Audio Compression Rate: 64 Kbps
Door Station/Network Parameters
- Ethernet: 10/100 Mbps Self-Adaptive Ethernet
- Network Protocol: TCP/IP, RTSP
Door Station/Device Interfaces
- IO Output: 1-ch 12 VDC Output
- RS-485: 1 RS-485 Half-Duplex Port
- Alarm Input: Door Magnetic Alarm, Tampering Alarm
- Network Interface: Two-Wire Interface
- I/O Input: 2
Door Station/General
- Material: Stainless Steel
- Power Consumption: ≤12 W
- Working Temperature: -30 °C to +60 °C (-22 °F to 140 °F)
- Working Humidity: 10% to 90%
- Dimension (L X W X H): 169 mm x 110 mm x 44 mm (6.65″ x 4.33″ x 1.73″)
- Protection Level: IP 65
- Power Input: Powered by DS-KAD709
Indoor Station/System Parameters
- Processor: High-Performance Embedded SOC Processor
Indoor Station/Display Parameters
- Display Screen: 7-inch Colorful TFT LCD
- Display Resolution: 1024 × 600
- Operation Method: Capacitive Touch Screen, Touch Button
- Operation Interface: Flattened UI Operation Interface
Indoor Station/Video Parameter
- Video Compression Standard: H.264
Indoor Station/Audio Parameters
- Audio Input: Built-in Omnidirectional Microphone
- Audio Output: Built-in Loudspeaker
- Quality: Noise Suppression and Echo Cancellation
Indoor Station/Device Interfaces
- Network Interface: Two-Wire Interface
- RS-485: 1, Half-duplex Interface
- Relay Output: 1
Indoor Station/General
- Power Supply: Powered by DS-KAD709
- Power Consumption: Max. 10 W
- Working Temperature: -10 ° C to +55 ° C (14 ° F to 131 ° F)
- Working Humidity: 10% to 90%
- Dimension (L X W X H): 196 mm × 133 mm × 25.75 mm (7.72″ × 5.24″ × 1.01″)
- Installation: Wall Mounting
Video Audio Distributor/Interfaces
- Interface Number: 1, 10/100M Interface
- Interface Type: 9-ch 2-wire Interface
Video Audio Distributor/General
- Power Supply: 24 VDC
- Power Consumption: 60 W
- Working Temperature: -10 ℃ to 55 ℃
- Working Humidity: 10% to 90%, No Condensing
- Dimension: 112.2 mm x 111 mm x 66 mm (4.42″ × 4.37″ × 2.60″)
