General
- Product Dimension (W × H × D): 111mm×56mm×47.7mm
- Package Dimension (W × H × D): 148mm×98mm×72mm
- Net Weight: 0.221 kg
- Packing List
- WiFi Extender× 1
- Quick Start Guide × 1
- Regulatory Compliance and Safety Information × 1
- Packing Method: Single pack
- Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity: 10% to 90% RH non-condensing
- Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity: 10% to 90% RH non-condensing
- Max. Power Consumption: ≤ 3.8 W
- Gross Weight: 0.192 kg
Wireless Parameter
- Data Rate
- ≤ 300 Mbps
- 2.4 GHz: 300 Mbps
- Wireless Standard: IEEE802.11b,IEEE 802.11g, IEEE 802.11n @2.4GHz
- Working Frequency Band: 2.4 GHz
- Transmitting Power: <20dBm
- Wireless Performance: 2*2 MIMO supported
- Receiving Sensitivity
- 2.4 GHz
- 11b-1M:-96dBm
- 11g-54M:-77dBm
- 11n-20M-MCS7:-75dBm
- 11n-40M-MCS7:-73dBm
- Antenna: 2*3dBi external antennas
Hardware Parameter
- LED Indicator: 1 * Signal/Power/WPS LED
- Reset
- 1 * WPS Button
- 1 * Reset Button
- Power Supply Method: 100-240V ~50/60HZ 0.3A
Software Function
- Application function: Repeater Mode
- Security Mode
- Default encryption mode: Mix WPA-PSK/WPA2-PSK
- WPA algorithm: TKIP
- Security Mechanism: Hide SSID
- Management Method: Web
- Upgrade: Web
- System Log: Firmware upgrade, Restore factory settings, Login password, and Reboot
