Description
General
- Product Dimension (W × H × D): 80mm×58mm×48mm
- Package Dimension (W × H × D): 95mm×98mm×120mm
- Net Weight: 0.221 kg
- Packing List
- WiFi Repeater × 1
- Power Adapter × 1
- Quick Start Guide × 1
- Regulatory Compliance and Safety Information × 1
- Packing Method: Single pack
- Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity: 10% to 90% RH non-condensing
- Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity: 10% to 90% RH non-condensing
- Max. Power Consumption: ≤ 5.2 W
- Gross Weight: 0.243 kg
Wireless Parameter
- Data Rate
- ≤ 1167 Mbps
- 2.4 GHz: 300 Mbps
- 5 GHz: 867 Mbps
- Wireless Standard: IEEE 802.11/a/n/ac wave 2 @5GHz, IEEE 802.11b/g/n @2.4GHz
- Transmitting Power: 14 ± 1.5 dBm @ 2.4G-mcs7; 14 ± 1.5dBm @ 5G-mcs9
- Wireless Performance: 2*2 MIMO supported
- Receiving Sensitivity
- -63 dB@AC80 -MCS9
- -89 dB@AC80 -MCS0
- Antenna: 2 * External 3dBi dual-band omni-directional antenna
Hardware Parameter
- Network Interface: 1*10/100Mbps RJ45
- LED Indicator
- 1 * Signal LED
- 1 * WPS LED
- 1 * Power LED
- Reset
- 1 * WPS Button
- 1 * Reset Button
- Power Supply Method: 9VDC, 0.8A, built-in
Software Function
- Application function: Repeater Mode，Access Point Mode
- Security Mode
- Default encryption mode: Mix WPA-PSK/WPA2-PSK
- WPA algorithm: TKIP
- Security Mechanism: Hide SSID
- Management Method: Web
- Upgrade: Web
- System Log: Firmware upgrade, Restore factory settings, Login password, and Reboot
