Description
Camera
- Lens: 2.8 mm, 3.6 mm, 6 mm fixed lens
- Horizontal Field of View: 85.5° (2.8 mm), 80.1° (3.6 mm), 57.1° (6 mm)
- Lens Mount: M12
- Day & Night: IR cut filter
- Synchronization: Internal synchronization
- Angle Adjustment: Pan: 0° to 355°; Tilt: 0° to 75°; Rotate: 0° to 355°
- Image Sensor: 5 MP CMOS image sensor
- Frame Rate
- PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps
- NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
- Resolution: 2560 (H) × 1944 (V)
- Min. illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time
- PAL: 1/25 s to 1/50, 000 s
- NTSC: 1/30 s to 1/50, 000 s
Menu
- AGC: Support
- Day/Night Mode: Auto/Color/BW (Black and White)
- White Balance: ATW/MWB
- Backlight Compensation: Support
- DWDR (Digital Wide Dynamic Range): Support
- Language: English, Chinese
- Functions: Brightness, Sharpness, DNR, Mirror, Smart IR
Interface
- Video Output: 1 HD analog output
- Switch Button: TVI/AHD/CVI/CVBS
General
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Power Supply: 12 VDC ±25%
- Power Consumption: Max. 4.3 W
- Protection Level: IP67, IK10
- Material: Metal
- IR Range: Up to 20 m
- Communication: Up the coax, Protocol: HIKVISION-C (TVI output)
- Dimensions: Ø 111 mm × 82.4 mm (Ø 4.4″ × 3.2″)
- Weight: [Approx. 350 g (0.77 lb.)
