DS-2CE16C2T-VFIR3 – Product Description
DS-2CE16C2T-VFIR3 – User Manual</a
| Model | DS-2CE16H1T-IT1 |
|---|---|
| Image Sensor: | 1.3MP CMOS Image Sensor |
| Signal System: | PAL/NTSC |
| Effective Pixels: | 1280(H)x960(V) |
| Min. Illumination: | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s |
| Lens: | 2.8-12mm @ F1.4 Angle of view: 97° – 30.4° |
| Lens Mount: | φ14 |
| Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360° |
| Day& Night: | IR cut filter with auto switch |
| Video Frame Rate: | 720p@25fps/720p@30fps |
| HD Video Output: | 1 Analog HD output |
| Synchronization: | Internal Synchronization |
| S/N Ratio: | More than 62 dB |
| Auto White Balance: | Auto / Manual |
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | 12 VDC±15% |
| Power Consumption: | Max. 4W |
| Weather Proof: | IP66 |
| IR Range: | Up to 40m |
| Communication : | Up the coax Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output) |
| Dimension: | 92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”) |
| Weight: | 1000 g |
