DS-2CD2H23G0-IZS
You are here: Home \ Products \ DS-2CD2H23G0-IZS

DS-2CD2H23G0-IZS

logo-2
1/2.8″ Progressive Scan CMOS
1920 ×1080@30fps
2.8 to 12 mm varifocal lens
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
H.265+, H.265, H.264+, H.264
Three streams
120dB WDR
2 Behavior analyses, and face detection
BLC/3D DNR/ROI
IP67, IK10
Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
3-Axis adjustment

Categories: , , ,

Description

Product Description : DS-2CD2H23G0-IZS

Model DS-2CD2H23G0-IZS
Image Sensor: 1/2.8″ Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter time: 1/3 s to 1/100,000 s
Slow shutter: Support
Lens: horizontal FOV: 110° to 31°
vertical FOV: 58° to 18°
diagonal FOV: 136° to 36°
Lens Mount: φ14
Adjustment Range: Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
Video bit rate: 32Kbps~16Mbps
Audio bit rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Triple Streams: Yes
Max. Image Resolution: 1920 x 1080
Frame Rate: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280×720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280×720)
Main Stream: 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
Image Enhancement: BLC/3D DNR
Image Settings: Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Regional Cropping: No
ROI: 1 fixed region for main stream and sub-stream
Day/Night Switch: Auto/Schedule/Triggered by alarm in
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
Alarm: 1 input, 1 output (up to 12 VDC, 30 mA), terminal block
Environment Noise Filtering: Support
Audio Sampling Rate: 16kHz / 32kHz / 44.1kHz / 48kHz
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Consumption: 12 VDC, 0.85A, max. 10W
PoE (802.3af, 37V to 57V), 0.35A to 0.2A, max. 12.5W
Impact Protection: IK10
Weather Proof: IP67
Dimensions: Φ 135.8 × 145.5 mm (Φ 5.4″ × 5.7″)
Weight: Camera: Approx. 1200 g (2.6 lb.)
With Package: Approx. 1580 g (3.5 lb.)
