Description
| General | |
|---|---|
| Length | 200m |
| Operating Temperature | -40-80ºC |
| Storage Temperature | -20-70ºC |
| Impedance | 75ohms |
| Impedance | 75ohms |
| Conductor | |
| Material | OFC(Oxygen Free Copper) |
| Diameter | 0.81±0.01mm |
| Wire Gauge | 20AWG |
| Insulation | |
| Material | FPE |
| Diameter | 3.66±0.05mm |
| Diameter | 3.66±0.05mm |
| Tape | |
| Material | Shielding Aluminum Foil, 15mmwidth |
| Thickness | 0.04mm |
| Braid | |
| Material | CCA(Copper-clad Aluminum) |
| Braiding Standard | 8*16*0.12mm |
| Braiding Density | 95±1% |
| Jacket | |
| Material | PVC |
| Average Thickness | ≥0.65mm |
| Diameter | 6.10±0.2mm |
